Unlike traditional toggle, pushbutton and rotary switches, rocker switches do not utilize a round threaded mounting bushing, and therefore a Rocker Boot does not include a threaded mounting nut.

In fact, most of APM Hexseal’s Rocker Boots do not include an insert or frame of any kind. The majority of our Rocker Boots are designed to install on the switch prior to the switch installation. Much like our Lever-Actuated Circuit Breaker Boots, APM Hexseal’s Rocker Boots are often molded from transparent silicone RUBRGLAS® which allows for easy viewing of the switch position.

Rocker Boots
Rocker Boots
MATERIAL SPECIFICATIONS

For APM Hexseal® Standard Rocker Boots

Elastomer:
APM HEXSEAL RUBRGLAS™ (transparent Silicone) conforms to A-A-59588, Class 3A, GR50 †
Temperature Range:
-103° F to +400° F ( -75° C to +204° C)
Resistant to:
Splash, salt spray, sunlight, ozone, weather, fungus, dust, and most acids and lubricating oils.
Shelf Life:
Excess of 25 years.
APM Hexseal
Part #
Height (A) Width 1 (B) Length 1 (C) Length 2 (D) Width 2 (E) Compatible Switches
(Partial List)
1113/62 0.297" 7.54mm 0.797" 20.24mm 0.687" 17.45mm 1.093" 27.76mm 0.968" 24.61mm Eaton/Arrow Hart
2600 Series
1113/66 0.228" 5.79mm 0.348" 8.84mm 0.531" 13.49mm 0.750" 19.05mm 0.531" 13.49mm Carling 611/621-Series
1113/70 0.297" 7.54mm 0.437" 11.10mm 0.875" 22.23mm 1.218" 30.94mm 0.640" 16.27mm Carling RSC-Series
1113/71 0.413" 10.49mm 0.687" 17.45mm 1.046" 26.57mm 1.327" 33.71mm 0.703" 17.86mm Carling M Series
Sensata/Airpax R11
Eaton/Heinemann LC-1
